5400HP / 4000kW Z-drive Tugboat
LOA: 38.30m | Breadth: 10.20m | Depth: 4.70m
Draft: 3.70m | GT: 428 | NT: 128
Bollard pull: 70 tonnes
Speed: ≥13 knots
Endurance: 1100 nautical miles
Crew: 10 persons
Navigation area: Offshore / Coastal
Class: CCS / ZC valid
2× main engines: G6300ZC44B, 2000kW each @750rpm
2× Z-drive full‑rotary azimuthing thrusters
2× fixed‑pitch propellers, diameter 2.4m
360° full rotation, 180° turn in 12 seconds
2× diesel generators: 120kW + 120kW
2× transformers 30kVA, emergency battery 780Ah
Full electrical system: 400V/230V/24V
External fire monitor: PSKDC150, 500m³/h, range 100m
Fire pump: 60m³/h, 0.48MPa
Oil-water separator: 0.25m³/h, ≤15ppm
Sewage treatment plant: compliant with MARPOL
2× Speke anchors: 662kg / 664kg
2× hydraulic windlasses
60t towing winch
Full life‑saving & fire‑fighting equipment
Offshore & coastal towing
Port maneuvering & berthing assistance
Salvage & rescue operations
Offshore engineering support
Firefighting & emergency response
Channel & terminal operations
Middle power: 5400HP / 4000kW for strong bollard pull
360° full‑rotary Z‑drive for excellent maneuverability
Dual engine + dual thruster system for high reliability
70 tonnes bollard pull for heavy‑duty towing
High speed up to 13 knots for fast response
Full offshore class & certificate ready to work
Built‑in fire monitor for multi‑purpose support
Stable hull & deep draft for rough sea conditions
Complete navigation & communication for offshore missions
Low fuel consumption & easy maintenance
