12000DWT COASTAL SUCTION & UNLOADING SAND CARRIER
FLAG: CHINA
CLASS: ZC
BUILT: FEB. 2016
LOA/B/D: 114.6/ 19.8 / 8.5 M
GRT/NRT: 6,602 / 3,697 T
DWT/DRAFT: 12000 T/ 6.2 M
DWCC: 8936 MT
M/E: GUANGCHAI 2000HPX2
G/E: WEICHAI 6160 (200KW X 2 SETS), WEICHAI 6160 (400KW X 1 SETS)
AUXILIARY G/E: 100KW X 4 SET
CONVEYOR BELT POWER: WARTSILA 4R32D (2500HP)
WIDTH OF CONVEYOR BELT: 2.0M
SAND SUCTION PUMP POWER: SHANCHAI 12PA6L-280(4800HP)
SAND SUCTION PUMP QTY: SINGLE 60M STARBOARD SIDE
SAND TUBE DIA: 813MM
WATER PIPE DIA: 930MM
WORK EFFICIENCY: SAND SUCTION 2.5-3H FULL LOAD.
UNLOADING: 55 MINUTES EMPTY.
Applications
Coastal sand mining and Dredging
Inshore port fairway maintenance & silt removal
Nearshore Reclamation & sand supply
Bulk sand transportation between coastal terminals
Offshore construction sand supply
Key Advantages
3‑in‑1 integrated function
Combines dredging, transportation, and self‑unloading in one unit; no need for separate dredgers, tugs, or shore‑based unloading equipment.
Deep and efficient sand extraction
Equipped with dedicated sand Pumps and suction pipes; can dredge sand down to 10–55m underwater, suitable for most coastal sand beds.
Bow‑belt conveyor , self‑unloading system
Continuous gravity‑fed discharge via hull‑bottom belts and bow conveyor; high efficiency, low dust, and precise positioning onshore.
Strong coastal adaptability
High economy & efficiency
Short turnaround time; reduces terminal investment, handling cost, and cargo damage.
Complete safety & auxiliary systems
Full set of navigation, communication, fire‑fighting, bilge treatment, and emergency power systems meeting statutory marine requirements.
