Home > Vessels For Sale > Split Hopper Barge > 1200m³ Split Hopper Barge
1200m³ Split Hopper Barge

    1200m³ Split Hopper Barge

    1200m³ Split Hopper Barge is a compact, agile vessel optimized for transporting dredged materials like sand, silt, and gravel in harbors, and coastal estuaries. Equipped with a hydraulic split-hull self-dumping system, it enables fast, independent unloading without auxiliary equipment, minimizing project turnaround time. Its reinforced lightweight steel structure and shallow draft ensure smooth navigation through narrow channels and shallow waters, making it a cost-effective pick for small to mid-sized dredging teams globally.
    Category：1200m³ Split Hopper Barge     Browse number：237     Release time：2026-01-23 10:11:49
  • Share：
    • Contact us Inquiry
  • E-mail：Info@yanyangmarine.com
    WhatsApp：15952900547

1200m³ Split Hopper Barge

Vessel Particulars

  • Type: Self-propelled split hopper barge

  • Length overall: 58.90 m

  • Breadth moulded: 12.60 m

  • Depth moulded: 4.20 m

  • Light draft: 1.71 m

  • Load draft: 3.00 m

  • Deadweight: 1137 t

  • Hopper capacity: 1200 m³

  • Navigation area: Coastal

  • Class: CCS / Valid until 2028

  • Crew: 10 persons

Main Machinery

  • Main engines: 2 × X6170ZC-1A / 382 kW

  • Gearbox: HCD400A, ratio 4.5:1

  • Hydraulic steering gear: XSF125-20

  • Hydraulic windlass: CMJ-28

  • Hydraulic system: 25 MPa


  • Applications

  1. Coastal Dredging and sludge transportation

  2. Port construction and waterway maintenance

  3. Sand, earth, and spoil handling

  4. Inshore engineering support


  • Advantages

  1. Low operating cost and competitive rental/price

  2. Sound hull condition and stable performance

  3. Easy operation and flexible maneuvering

  4. Reliable machinery and complete equipment

  5. Certified for coastal navigation, valid class


Related tags： 1200m³ Split Hopper Barge motor hopper , bottom dumping barge
